HARDWARE FEATURES
Interface USB 3.0
Button WPS button
Wireless Standards
Dimensions ( W x D x H ) 3.96×1.44×0.56in. (100.53×36.6×14.3mm)
Antenna
Antenna Type Omni Directional
WIRELESS FEATURES
Wireless Standards IEEE 802.11ac, IEEE 802.11a,IEEE 802.11n,IEEE 802.11g, IEEE 802.11b
Frequency 5GHz,2.4GHz
Signal Rate 5GHz:
11ac: Up to 1300Mbps(dynamic)
11n: Up to 450Mbps(dynamic)
11a: Up to 54Mbps(dynamic)
2.4GHz:
11n: Up to 600Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Transmit Power <20dBm (EIRP)
Wireless Modes Ad-Hoc / Infrastructure mode
Wireless Security Support 64/128 bit WEP, WPA-PSK/WPA2-PSK, 802.1x
Modulation Technology DBPSK, DQPSK, CCK, BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
OTHERS
Certification FCC, RoHS
Package Contents Wireless Adapter Archer T9UH
Resource CD
Quick Installation Guide
USB Cradle
System Requirements Windows 11/10/8.1/8/7/XP (32/64bits), Mac OS 10.9~10.13
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
